The main indicators of transformer health are oil level and top oil temperature. Further, being highly optimized for cost, these transformers have very minimal instrumentation.
Simit Pradhan and the Corporate Technology team at Siemens developed a health monitoring system that remotely senses the oil level using temperature sensors fitted on the transformer housing. A physics-based model of the transformer enables the team to relate the temperature measurements to the amount of oil present in real time. This non-invasive solution can be retrofitted on any ONAN transformer and enable real-time condition monitoring of the asset.
The next step in implementation was field deployment. The team used MATLAB Production Server™ to deploy their algorithms to the cloud. Prototype IoT devices deployed on individual transformers stream data to the cloud, where the algorithm generates signals for predictive maintenance of the respective assets.
